Specification
3.5"/2.5" Universal drive brackets
6
Dedicated 2.5" drive brackets
2
Dedicated 5.25" drive bracket
1 (removable)
Expansion slots
7 + 2 vertical
Motherboard compatibility
eATX (up to 285mm wide), ATX, mATX, ITX
Power supply type
ATX
Front ports
2 x USB 3.0, 2 x USB 2.0
Total fan mounts
9
Front fan
3 x 120 mm or 2 x 140 mm,
2 x Dynamic X2 GP-14 included
Top fan
Standard layout: 3 x 120 or 2 x 140
Open layout: 3 x 120/140 mm
Rear fan
1 x 120/140 mm
1 x Dynamic X2 GP-14 included
Bottom fan
2 x 120/140 mm
Dust filters
Bottom fan + PSU
Front fans
Top panel
Front radiator
120/240/360 mm 140/280 mm
Top radiator
Standard layout: - 120/240/360 mm (max 35 mm motherboard component height)
Open layout: - 120/240/360 mm - 140/280/420 mm (max 35 mm motherboard component height)
Rear radiator
120 mm
Bottom radiator
120/240 mm 140/280 mm
PSU max length
300 mm
GPU max length
Max 440mm with front fan mounted
Standard layout: Maximum width 155 mm (including power connectors) for graphics cards longer than 300mm.
CPU cooler max height
185 mm
Cable routing space
23 mm
Cable routing grommets
Yes
Fixed velcro straps
Yes
Tool-less push-to-lock
Both side panels
Captive thumbscrews
HDD brackets,
SSD brackets
Left side panel
Industrial sound-dampened steel
Right side panel
Industrial sound-dampened steel
Case dimensions (LxWxH)
543 x 233 x 465 mm
Case dimensions w/o feet/protrusions/screws
535 x 233 x 448 mm
Net weight
12.4 kg
Package dimensions (LxWxH)
560 x 347 x 650mm
Package weight
14.4 kg
