Moding - Cooling

Bequiet CPU AIR COOLER DARK ROCK PRO 5 BK036. TDP: 270W Supported Platforms: Intel 1700/ 1200/ 1150/ 1151/ 1155, AMD MA5/AM4 Color: Black Dimensions with fan: 145 x 136 x 168 (L x W x H in mm) Total weight: 1.29kg Overall noise level (dB(A)) @ 50/75/100% rpm: 8.9 / 16.3 / 23.3 Number of fans: 2 Heatsink specifications: Dimensions: 119.5 x 136 x 168mm (L x W x H) Fin material: Aluminum Surface treatment: Ceramic coating Base material: Copper CPU contact surface: CNC machined Heatpipe number: 7 Heatpipe diameter: 6mm Fan specifications: Fan model: Silent Wings / Silent Wings 4 Fan dimensions: 135 x 135 x 25mm / 120 x 120 x 25mm Speed @ 100% PWM /12V: 1300; 1500rpm / 1700; 2000rpm Bearing technology: Fluid Dynamic Bearing Motor technology: 6-pole fan motor Rated Voltage (V): 12 Input current (A): 0.28 / 0.20 Input power (W): 3.36 / 2.4 Connector: 4-pin PWM Cable length (mm): 120 / 80 Lifespan (h / 25°C): 300.000 Y-Cable: ✓ Accessories Thermal grease: Included Mounting set: Intel, AMD Screwdriver Safety certification: Approvals CE, UKCA, UL, TÜV Environmental directives: RoHS, WEEE, Triman

HEATSINK REF LIQUID Thermaltake 280 ARGB SYNC 2 VEN 140MM ARGB MULTISOCKET

Cooler Specification Socket compatibility AMD TR4 & SP3 Height (without fan) 165 mm Width (without fan) 150 mm Depth (without fan) 52 mm Height (with fan) 165 mm Width (with fan) 150 mm Depth (with fan) 78 mm Weight (without fan) 865 g Weight (with fan/s) 1030 g Material Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating Max. TDP see TDP guide Fan compatibility 140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25 Scope of delivery NF-A15 PWM premium fan Low-Noise Adaptor (L.N.A.) NT-H1 high-grade thermal compound SecuFirm2™ mounting kit Anti-vibration pads and fan-clips for second NF-A15 (optional) Noctua metal case-badge Warranty 6 Years FAN Specification Model Noctua NF-A15 PWM Bearing SSO2 Max. Rotational Speed (+/- 10%) 1500 RPM Max. Rotational Speed with L.N.A. (+/- 10%) 1200 RPM Min. Rotational Speed (PWM, +/-20%) 300 RPM Max. Airflow 140,2 m³/h Max. Airflow with L.N.A. 115,5 m³/h Max. Acoustical Noise 24,6 dB(A) Max. Acoustical Noise with L.N.A. 19,2 dB(A) Input Power 1,56 W Voltage Range 12 V MTTF > 150.000 h

Compatibillity: Intel:1700 AMD: AM5, AM4 PI | NNPI: 319 | 259 TIM: MX-6 (0.8 g) Warranty:6 Years Operating Ambient Temperature: 0—40 °C Weight: 1870 g All-In-One Connector:4-Pin PWM Connector Splitt Connector:3x 4-Pin PWM Connector Pump: 800—2800 rpm (PWM controlled) Current | Voltage:0.35 A | 12 V DC Cold Plate:Copper, Micro Skived Fins Tube Length:450 mm Tube Diameter: Outer: 12.4 mm Inner: 6.0 mm Radiator Material: Aluminium Dimensions: 317 (L) x 138 (W) x 38 (H) mm VRM Module VRM Fan: 400—2500 rpm (PWM controlled) Current | Voltage: 0.05 A | 12 V DC Radiator Fans Fan: 2x P14 PWM PST A-RGB Speed:200—1900 rpm Air Flow: 69.90 cfm | 123.76 m3/h Static Pressure:1.82 mmH2O Bearing:Fluid Dynamic Bearing Current | Voltage:0.17 A | 12 V DC Cable Lenght:40 mm Connector:4-Pin PWM Connector
