| P/N | CA-1R3-00S6WN-00 |
|---|---|
| SERIES | The Tower |
| MODEL | The Tower 100 Snow |
| CASE TYPE | Mini Tower |
| DIMENSION (H X W X D) | 462.8 x 266 x 266 mm (18.2 x 10.5 x 10.5 inch) |
| NET WEIGHT | 6.1 kg / 13.45 lbs. |
| SIDE PANEL | Tempered Glass x 3 (4mm thickness) |
| COLOR | Black |
| MATERIAL | SPCC |
| COOLING SYSTEM | Top(exhaust): 120 x 120 x 25 mm Turbo fan (1000rpm, 16 dBA) x 1 Rear(exhaust): 120 x 120 x 25 mm Turbo fan (1000rpm, 16 dBA) x 1 |
| DRIVE BAYS -ACCESSIBLE -HIDDEN |
- 2 x 2.5“(with side bracket); 2 x 3.5” (without rear fan) |
| EXPANSION SLOTS | 2 |
| MOTHERBOARDS | 6.7” x 6.7” (Mini ITX) |
| I/O PORT | USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 2 |
| PSU | Standard PS2 PSU (optional) |
| FAN SUPPORT | Top: 1 x 120mm, 1 x 140mm Rear: 1 x 120mm, 1 x 140mm Top of the PSU Cover: 1 x 120mm, 1 x 140mm |
| RADIATOR SUPPORT | Top: 1 x 120mm |
| CLEARANCE | CPU cooler height limitation: 190mm VGA length limitation: 330mm PSU length limitation: 180mm |
