MODEL
View 51 TG Snow
CASE TYPE
Middle Tower
DIMENSION (H X W X D)
550 x 315 x 525 mm
(21.65 x 12.4 x 20.67 inch)
SIDE PANEL
3 x Tempered Glass (4mm thickness)
COLOR
Exterior & Interior: White
MATERIAL
SPCC
COOLING SYSTEM
Front (intake) :
2 x 200 x 200 x 30mm Addressable RGB fan
(Fixed 600rpm, 24dBA)
Rear (exhaust) :
1 x 120 x 120 x 25mm Addressable RGB fan
(Fixed 1000rpm, 27.2 dBA)
DRIVE BAYS
-ACCESSIBLE
-HIDDEN
2 x 3.5’’ or 2.5’’ (With HDD Cage) ; 2 x 2.5’’ (With HDD Bracket)
-
EXPANSION SLOTS
8
MOTHERBOARDS
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX), E-ATX (up to 10.5'' wide)
I/O PORT
1 x Type-C, 2 x USB 2.0, 2 x USB 3.0, 1 x HD Audio
PSU
Standard PS2 PSU (optional)
FAN SUPPORT
Front: 3 x 120mm , 3 x 140mm , 2 x 200mm
Top: 3 x 120mm , 3 x 140mm , 2 x 200mm
Rear: 1 x 120mm ,
Right: 3 x 120mm , 2 x 140mm
Bottom: 3 x 120mm
RADIATOR SUPPORT
Front: 1 x 360mm , 1 x 280mm ,
Top: 1 x 360mm , 1 x 280mm ,
Right: 1 x 360mm , 1 x 280mm
Bottom: 1 x 360mm ,
CLEARANCE
CPU cooler height limitation: 175mm
VGA length limitation: 300mm(With Water Pump)
440mm(Without Water Pump)
PSU length limitation: 200mm
