Τροφοδοτικά

Type PC Power Supply colour black EAN 4711246873964 Manufacturer no. PS SPR 0750NHSABE-1 power total 750 W + 12V Total 672 W + 3.3V / + 5V total 100 W efficiency Up to 88% Input voltage range 230 volt installation standard ATX12V 2.4, EPS12V 2.9x design ATX certification 80 PLUS Bronze 230V EU currents +3.3 V 24 A +5 V 18 A +5 Vsb 2.5 A -12 V 0.5 A +12 V Total 56 A +12 V1 56 A Power Factor Correction Active PFC connections 8x 15-pin SATA, 1x 20-pin ATX, 1x 24-pin ATX12V 2.x, 1x 4 + 4-pin 12V, 4x 4-Pin-5.25 ", 4x 6 + 2-Pin -Graphic cooling Fans 1x 120 mm fan regulation temperature controlled feature 10 individually adjustable LEDs, RGB colors 256 equipment available 1x floppy adapter Dimensions Width: 150 mm x height: 86 mm x depth / length: 140 mm

80 PLUS Certification: Gold Form Factor: ATX 2.3 Continuous Power: 550 W ErP Compliant: ✓ Active PFC: ✓ Technology: LLC + DC/DC MTBF: Min. 100,000 Hours Operating Temperature: 0 °C - 40 °C Standby Power Consumption: Max. 0.3 W Weight incl. Fixed Cables: 1.61 kg Dimensions (L x W x H): 150 x 160 x 86 mm Housing Color: Black Cable and Connectors Cable Configuration: Semi-Modular Flat Cables: ✓ Maximum Cable Length: 85 cm Cable Length Mainboard Connector: 55 cm Cable Length CPU Connector: 55 cm Cable Length PCIe Connector: 55 cm Cable Length to First Peripheral Connector: 55 cm 24-Pin Mainboard Connector: 1 4+4-Pin CPU Connector: 2 6+2-Pin PCIe Connector: 4 SATA Connector: 9 IDE Connector: 3 Floppy Connector: 1

Type Intel ATX 12V 2.3 Max. Output Capacity 700W Color Black Dimension (H x W x D) 86mm x 150mm x 140mm PFC （Power Factor Correction） Active PFC Power Good Signal 100-500 msec Hold Up Time 16msec (minimum) within 60% load Input current 12A max Input Frequency Range 50 Hz - 60 Hz Input Voltage 100Vac - 240Vac Operating Temperature 5℃ to +40℃ Operating Humidity 20% to 85%,non-condensing Storage Temperature -40 ℃ to +55 ℃ Storage Humidity 10% to 95%, non-condensing Cooling System 120mm Fan: 1800 R.P.M. ± 10% Efficiency 80-87% efficiency @ 20-100% load MTBF 100,000 hrs minimum Safety Approval CE/CB/TUV/ UL/ FCC/ EAC P/N PS-SPR-0700NHFAWx-1 Protection OVP, OPP, SCP

Εξαιρετικά υψηλή απόδοση Ενσωματωμένο σιωπηλό ανεμιστήρα 140 χιλ. Καθαρή ισχύς 845 watt 5 x Sata 1 x 20 + 4pin Μητρική πλακέτα 2 x 6 + 2pin PCI-E 1 x 4 + 4pin CPU + 12v 3 x 4pin HDD

80 PLUS Certification: Gold Form Factor: ATX 2.3 Continuous Power: 650 W ErP Compliant: ✓ Active PFC: ✓ Technology: LLC + DC/DC MTBF: Min. 100,000 Hours Operating Temperature: 0 °C - 40 °C Standby Power Consumption: Max. 0.3 W Weight incl. Fixed Cables: 1.61 kg Dimensions (L x W x H): 150 x 160 x 86 mm Housing Color: Black Cable and Connectors Cable Configuration: Semi-Modular Flat Cables: ✓ Maximum Cable Length: 85 cm Cable Length Mainboard Connector: 55 cm Cable Length CPU Connector: 55 cm Cable Length PCIe Connector: 55 cm Cable Length to First Peripheral Connector: 55 cm 24-Pin Mainboard Connector: 1 4+4-Pin CPU Connector: 2 6+2-Pin PCIe Connector: 4 SATA Connector: 9 IDE Connector: 3 Floppy Connector: 1

Ισχύς700 W Τύπος PFCActive ΤύποςATX ModularSemi Modular Certification80 PLUS Bronze Διάσταση Ανεμιστήρα120 mm Προστασία ΙσχύοςOver Current Protection (OCP), Over Power Protection (OPP), Over Temperature Protection (OTP), Over Voltage Protection (OVP), Short Circuit Protection (SCP), Under Voltage Protection (UVP)
