The Wireless Recorder is used to record videos and secure your home or business. Without the limitation of the network cable, cameras connect to the recorder via Wi-Fi, and could be placed freely in any corner.
4-Channel Wi-Fi NVR
Wired Max. Input: 40Mbps
Wireless Max .Input: 16Mbps
Operation Display: WEB/GUI/Imou Life App
Videon in: 4 channels
Video Out: 1x HDMI, 1x VGA
Network: ONVIF Profile T/S/G, CGI, SDK, Wi-Fi: IEEE802.11b/g/n, 100m Open Field Internal Dual-antenna, 2×2 MIMO
Imou App: IOS, Android
Auxiliary Interface: 2x USB Ports, 1x SATA Port, 1x Network Port, 1x RCA In, 1x RCA Out, 1x HDMI Port, 1x VGA Port, 1x Power Port
Two-way Talk
Recoding & Decoding:
Resolution: 1080P/720P
Max Decoding: 1ch @6MP/2ch @4MP/4ch @1080P/8ch @720P
Compression: Smart H.265+/H265/H.264+/H.264
Audio Compression: G.711A/G.711U/PCM/G726/AAC
Function:
Recoder Mode: Manual/Alarm/Motion detection/Schedule
Backup Mode: USB Device
Playback: 1/4
Storage: Up to 8TB HDD/Cloud Storage
Multi-screen Display: 4ch 1/4
Power Supply: DC12V 1.5A
Power Consumption: ≤10W(without HDD)
Operating Conditions: -10℃～+45℃, 10℅～90℅RH
