Compatibillity:
Intel:1700
AMD: AM5, AM4
PI | NNPI: 319 | 259
TIM: MX-6 (0.8 g)
Warranty:6 Years
Operating Ambient Temperature: 0—40 °C
Weight:1705 g
All-In-One Connector:4-Pin PWM Connector
Splitt Connector:3x 4-Pin PWM Connector
Pump: 800—2800 rpm (PWM controlled)
Current | Voltage:0.35 A | 12 V DC
Cold Plate:Copper, Micro Skived Fins
Tube Length:450 mm
Tube Diameter:
Outer: 12.4 mm
Inner: 6.0 mm
Radiator
Material: Aluminium
Dimensions: 317 (L) x 138 (W) x 38 (H) mm
VRM Module
VRM Fan: 400—2500 rpm (PWM controlled)
Current | Voltage: 0.05 A | 12 V DC
Radiator Fans
Fan: 2x P12 PWM
Speed:200—1800 rpm
Air Flow:
72.80 cfm | 123.76 m3/h
Static Pressure:2.40 mmH2O
Bearing:Fluid Dynamic Bearing
Current | Voltage:0.12 A | 12 V DC
Cable Lenght:40 mm
Connector:4-Pin PWM Connector
