Moding - Cooling

Radiator: Dimensions: 274 x 120 x 27 mm (L x W x H) Material: Aluminium, Plastic Water Cooling Pipe Length: 395 mm, braided sleeves Fans: 2x 120 mm Dimensions: 120 x 120 x 25 mm (L x W x H) Fan Bearing: Fluid Dynamic Bearing Connectors: 4 Pin PWM / 3 Pin ARGB (5VDG) Speed: max 2,200 RPM Air Flow: max 110.78 m³/h (65.2 CFM) Air Pressure: max 3.9 mmH2O Fan Noise: max 30 dB(A) Life Expectancy: 40,000 hours Rated Voltage: 12 V DC Voltage Range: 0 to 13.2 V Rated Current: 0.246 A Power Consumption: 3 W Cooler/Pump: Dimensions: 72 x 72 x 48 mm (L x W x H) Pump motor speed: 2,600 RPM Noise Level: 30 dB(A) Connector: 3 Pin Lighting: ARGB, 3-Pin RGB (5VDG, 5V) Life Expectancy: 40,000 hours Rated Voltage: 12V DC Rated Current: 0.24 A Power Consumption: 3 W Compatibility (Socket): Intel: LGA 1700 / 1200 / 115x / 2066 / 2011-V3 / 2011 / 1366 AMD: AM5 / AM4 / AM3+ / AM3 / AM2+ / AM2 / FM2+ / FM2 / FM1 Radiator: Dimensions: 394 x 120 x 27 mm (L x W x H) Material: Aluminium, Plastic Water Cooling Pipe Length: 395 mm, braided sleeves Fans: 3x 120 mm Dimensions: 120 x 120 x 25 mm (L x W x H) Fan Bearing: Fluid Dynamic Bearing Connectors: 4 Pin PWM / 3 Pin ARGB (5VDG) Speed: max 2,200 RPM Air Flow: max 110.78 m³/h (65.2 CFM) Air Pressure: max 3.9 mmH2O Fan Noise: max 30 dB(A) Life Expectancy: 40,000 hours Rated Voltage: 12 V DC Voltage Range: 0 to 13.2 V Rated Current: 0.246 A Power Consumption: 3 W Cooler/Pump: Dimensions: 72 x 72 x 48 mm (L x W x H) Pump motor speed: 2,600 RPM Noise Level: 30 dB(A) Connector: 3 Pin Lighting: ARGB, 3-Pin RGB (5VDG, 5V) Life Expectancy: 40,000 hours Rated Voltage: 12V DC Rated Current: 0.24 A Power Consumption: 3 W Compatibility (Socket): Intel: LGA 1700 / 1200 / 115x / 2066 / 2011-V3 / 2011 / 1366 AMD: AM5 / AM4 / AM3+ / AM3 / AM2+ / AM2 / FM2+ / FM2 / FM1

Compatibillity: Intel:1700 AMD: AM5, AM4 PI | NNPI: 319 | 259 TIM: MX-6 (0.8 g) Warranty:6 Years Operating Ambient Temperature: 0—40 °C Weight:1705 g All-In-One Connector:4-Pin PWM Connector Splitt Connector:3x 4-Pin PWM Connector Pump: 800—2800 rpm (PWM controlled) Current | Voltage:0.35 A | 12 V DC Cold Plate:Copper, Micro Skived Fins Tube Length:450 mm Tube Diameter: Outer: 12.4 mm Inner: 6.0 mm Radiator Material: Aluminium Dimensions: 317 (L) x 138 (W) x 38 (H) mm VRM Module VRM Fan: 400—2500 rpm (PWM controlled) Current | Voltage: 0.05 A | 12 V DC Radiator Fans Fan: 2x P14 PWM Speed:200—1700 rpm Air Flow: 72.80 cfm | 123.76 m3/h Static Pressure:2.40 mmH2O Bearing:Fluid Dynamic Bearing Current | Voltage:0.12 A | 12 V DC Cable Lenght:40 mm Connector:4-Pin PWM Connector

Compatibillity: Intel:1700 AMD: AM5, AM4 PI | NNPI: 319 | 259 TIM: MX-6 (0.8 g) Warranty:6 Years Operating Ambient Temperature: 0—40 °C Weight:1705 g All-In-One Connector:4-Pin PWM Connector Splitt Connector:3x 4-Pin PWM Connector Pump: 800—2800 rpm (PWM controlled) Current | Voltage:0.35 A | 12 V DC Cold Plate:Copper, Micro Skived Fins Tube Length:450 mm Tube Diameter: Outer: 12.4 mm Inner: 6.0 mm Radiator Material: Aluminium Dimensions: 317 (L) x 138 (W) x 38 (H) mm VRM Module VRM Fan: 400—2500 rpm (PWM controlled) Current | Voltage: 0.05 A | 12 V DC Radiator Fans Fan: 3x P12 PWM Speed:200—1800 rpm Air Flow: 72.80 cfm | 123.76 m3/h Static Pressure:2.40 mmH2O Bearing:Fluid Dynamic Bearing Current | Voltage:0.12 A | 12 V DC Cable Lenght:40 mm Connector:4-Pin PWM Connector

Compatibillity: Intel:1700 AMD: AM5, AM4 PI | NNPI: 319 | 259 TIM: MX-6 (0.8 g) Warranty:6 Years Operating Ambient Temperature: 0—40 °C Weight: 2325 g All-In-One Connector:4-Pin PWM Connector Splitt Connector:3x 4-Pin PWM Connector Pump: 800—2800 rpm (PWM controlled) Current | Voltage:0.35 A | 12 V DC Cold Plate:Copper, Micro Skived Fins Tube Length:450 mm Tube Diameter: Outer: 12.4 mm Inner: 6.0 mm Radiator Material: Aluminium Dimensions: 317 (L) x 138 (W) x 38 (H) mm VRM Module VRM Fan: 400—2500 rpm (PWM controlled) Current | Voltage: 0.05 A | 12 V DC Radiator Fans Fan: 2x P12 PWM PST A-RGB Speed:200—2000 rpm Air Flow: 48.82 cfm | 123.76 m3/h Static Pressure:1.82 mmH2O Bearing:Fluid Dynamic Bearing Current | Voltage:0.12 A | 12 V DC Cable Lenght:40 mm Connector:4-Pin PWM Connector
